Touchscreen keypads with capacitive technology
– 8” screen size
– Android 11 operating system
– ABS frame
– Resolution: 800 x 1280
– Handles functions: Burglar Alarm, Video Verification, Smart Home Automation, Video Intercom on SIP protocol
– Intercom function
– Live view function of cameras on the network
– Communication with the control panel on proprietary protocol
– Connection via TCP-IP in LAN and/or Wi-Fi network and back up on RS485*
– Power supply either 12-24Vdc or POE (Power over Ethernet)
– Power consumption: 450mA
– Mounting on DIN 503 boxes or round boxes pitch 60 mm
– Dimensions mm: 200 x 124.6 x 37.7
– Compatibility: ULTRA range

*Some functions will not be available from the first version but will be added later
